Maritime surveillance and communications for a South-East Asia Royal sailing event

The objective was to provide high speed internet, tracking and audio/video communications at the Maritime Police HQ some 400Km distant, using our Hypha Mesh and Starlink LEO SATCOM.

Three ships were “meshed” together so they could all communicate via the Starlink on the Mothership. Distances from the Mothership varied, with the maximum distance being >10Km from the second ship to the Mothership, and <2Km from the RHIB to the Mothership.

Using 2W IP Mesh radios, operating at 10MHz bandwidth, in C band (4800-5000MHz), with 3dBi omni antennae, data throughput across the small IP Mesh network was stable at 11mbps, far exceeding the required minimum of 3mbps, while the Starlink up and downlink also far exceeded this requirement. Users on all three vessels enjoyed seamless, uninterrupted, high speed internet access, as well as high quality video and audio.

Live tracking, and event management was provided by the Scytalys MIMS Ranger Marine Interdiction Operations (MIO) plug-in, running on rugged Android devices, connected over the Hypha Mesh radios, via the integral Wi Fi on every Hypha Mesh IP Mesh radio, streamed live to Marine Police HQ and Navy HQ.

This exercise further cements our position as the premier IP Mesh Maritime/SATCOM solution provider, delivering high speed ship-to-ship and ship-to-shore network connectivity at sea, and wherever communications are required, in the most demanding environments, and in the absence of any public infrastructure network.

Images are redacted at the request of the end user agencies involved. Please contact us for further technical details of the configuration and results.

mMesh UI

mMesh UI showing signal strengths between radios/nodes

Upload and download speeds achieved

Video of similar demonstration using our Hypha Mesh with satcom.
